HX-360B/500B Fctory Various Plastic metal Materials Cutting Machine

Using man-machine interface + PLC control system and pneumatic ejection device, it can do special cutting with multiple cuts, half cuts and one cut. The cutting length can be set in 5 different sizes, and different cutting numbers and cycles can be set to increase Cutting efficiency, high precision, low loss and simple operation.
Size:
Availability:
Quantity:
  • HX-360B

  • Hexin

1. Product name:Computer cutting machine

Factory direct support customization

360B详情1


2. Six Advantages:

Factory direct sales

Time guarantee

Experience guarantee

Material guarantee

Price guarantee

After-sale warranty

360B详情2


3. Products Features

1. Science and technology Manufacturing quality assurance

We work hard to develop machinery,

Only provide you with high-quality products

360B详情3


2. Born for efficiency

Convenient operation and high efficiency,

We give you more than just It's a cutting machine

360B详情5


4. Product parameter:

Model

HX-360B

Cutting Length

0.1~9999.9mm

Cutting Width

1~360mm

Power

1.5HP

Voltage

220V/380V

N.W./ GW.

240/260kg

Measurement

980x1450x1070mm

5. Best quality

Because of quality we trust more,

Trust more because of quality


1. HMI:Using man-machine interface + PLC

Control system Integrated with pneumatic pushing device


2. Reasonable design:

Model design accords with ergonomics Principle of Operation


3. Easy to operate:

Can do multiple cuts, half breaks, one cut

Special cutting, sheet length can be set
Set 5 different sizes


4. Multiple slices

Can do multiple cuts, half breaks, one cut

Special cutting, slice length can be set

Set 5 different sizes


6. Omnidirectional display

1. The appearance is atmospheric and the interior is practical and durable


2. Excellent shell material, reasonable structure and guaranteed quality


3.Manufacturers direct sales, support processing and customization, and directly yield profits to consumers


7. Certificates

70

8.sample

切片样


Taiwan Brand Servo motor & Japan brand PLC applied

Multi-cutting models can be set according to your needs

5 different lengths can be set in a cutting circle, cycling times can also be set

Cutting length and cutting speed adjustable.

Optional kiss-cut (several times kiss-cut)+full-cut (one time full-cut) available

Optional kiss-cut(half-cut) available.


Sizing cutting for conductive fabric, foam, reflector film, double-sided adhesive tape, nickel plate, PET,PC,PE insulation paper, copper /aluminum foil and all kinds of adhesive tapes.


Model

HX-360B

HX-500B

Voltage

380V

380V

Total Power

1.3KW

1.3KW

N.W.

220kg

240kg

GW.

240kg

260kg

Cutting Width

1-360mm

1-500mm

Cutting Length

0.1-9999.9mm

0.1-9999.9mm

Packing Size

780x920x1300mm

980x1450x1070mm
